Made to Measure Wardrobe Installation Guide: 2026 Steps
Table of Contents
- Wardrobe Installation Tools List: What You Need Before You Start
- Step 1: Measuring the Opening and Preparing the Room
- Step 2: Assembling and Levelling the Cabinet Carcass
- Step 3: Sliding Wardrobe Door Track Installation
- How to Scribe Wardrobe Side Panels to Uneven Walls
- Step 4: Hanging Doors and Adjusting Alignment
- Common Mistakes, Maintenance and Waste Management
- Conclusion
- Frequently Asked Questions
Last Updated: September 12, 2026
Wardrobe Installation Tools List: What You Need Before You Start
A made to measure wardrobe installation guide lives or dies on preparation, and that starts with having the right kit on the floor before you touch a single panel. This guide from DoorsDirect covers everything a competent DIYer or joiner needs to fit a sliding wardrobe properly.
Most guides treat the tools list as an afterthought. In practice, missing one item mid-install turns a two-hour job into a two-day one. Gather everything first, and match your fixings to the wall before you drill.
Core tools and equipment:
- Measuring tape (5m minimum) and a pencil
- Spirit level (900mm or longer) and plumb line
- Power drill with masonry, wood and multi-material drill bits
- Screwdriver set and Allen keys (metric and imperial if the kit is imported)
- Spacer blocks, packers and shims
- Fine-tooth saw (10-12 TPI) for scribing
- Step ladder and a second pair of hands
- Vacuum and dust sheets
Fixings by wall type, this is where most installs fail:
- Solid masonry (brick, block, stone): use a masonry bit and a plug-and-screw fixing sized to the load. A top track carrying two 25kg doors needs fixings rated well above that static load, because the dynamic pull when a door is yanked is far higher (bsigroup.com).
- Plasterboard over studwork: locate the studs with a detector and fix directly into timber where possible. Where you must fix into the board itself, use a heavy-duty cavity fixing (the metal toggle or self-drill type), never a standard plastic plug, those pull straight through under load.
- Plasterboard over dot-and-dab: the board sits on adhesive dabs with a void behind. Standard plugs have nothing to grip. Use a specialist drywall fixing long enough to reach the solid wall behind, or cut back and fix into the masonry.
- Lath and plaster (common in older properties): treat as a void wall and use cavity fixings, or better, find the timber studs behind the lath.
You'll also want the manufacturer's installation manual to hand. DoorsDirect supplies one with every made-to-measure set, alongside a guide to safe DIY power tool use worth reading before you drill into a wall.
Nice-to-have but genuinely useful:
- A laser level, which speeds up track alignment considerably on longer openings
- A stud finder with a live-wire detector, for safety as much as accuracy
- A rubber mallet for seating panels without marking them
- Masking tape for marking cut lines on melamine or MDF without scratching the surface
Budget half an hour to lay everything out and read the manual end to end before you start.
Step 1: Measuring the Opening and Preparing the Room
Measure the opening width at three points (top, middle, bottom) and the height at both sides, then work to the smallest figure. Made-to-measure doors are cut to your supplied dimensions, so accuracy decides whether the finished wardrobe fits.
Clear the room before you start: remove skirting in the wardrobe footprint, protect the floor, and check the ceiling and walls are sound enough to take fixings. DoorsDirect offers measurement guidance as part of its made-to-measure service.
Checking Floor Level and Wall Straightness
Floors and walls are rarely true, and a wardrobe fitted to an uneven floor will show gaps or bind on the track. Run a spirit level across the floor where the carcass will sit, and note how much any slope drops across the opening so you can correct for it when levelling.
Hold a straight edge against the wall and look for bows or dips. Anything more than a few millimetres out means you'll need to scribe the side panels rather than butt them flush.
Step 2: Assembling and Levelling the Cabinet Carcass
The cabinet carcass carries the doors, so it must be square and level before anything else goes on. Assemble it flat on the floor following the manual's sequence, then stand it into position.
Check for square by measuring diagonally corner to corner. Both measurements should match. If they don't, the carcass will twist and the doors will never sit correctly.
Floor Levelling Techniques for Uneven Floors
Use adjustable feet or spacer blocks under the carcass, packing the low side until the spirit level reads true. Check front-to-back as well as side-to-side, because a carcass level in one plane but not the other will still throw the doors out.
Once level, anchor the carcass to the wall, locating studs where possible and using masonry fixings for solid walls. This anchoring step gives the unit its structural integrity, so don't skip it.
Step 3: Sliding Wardrobe Door Track Installation
Sliding wardrobe door track installation is where the job succeeds or fails. The top track carries the door weight and the bottom track guides it, so both must be dead level and parallel.
Fix the top track first, using the plumb line to mark its position directly above where the bottom track will sit. Screw it into studs or use masonry fixings, spaced evenly along the length.
Fitting Top and Bottom Tracks Level
Mark the bottom track position using a plumb line dropped from the top track, then fix it. Check both tracks with the spirit level again after fixing, since tightening screws can pull a track out of true.
The two tracks must be parallel. If the top track sits further forward than the bottom, doors will drift; if it sits further back, they'll bind. Measure the gap between tracks at both ends and the middle to confirm.
How to Scribe Wardrobe Side Panels to Uneven Walls
Scribing means cutting a panel's edge to match the contour of an uneven wall so it sits flush without gaps. It's the step that separates a professional-looking fit from an obviously DIY one.
Set the panel in position and use a compass or scribing block to transfer the wall's profile onto the panel edge. Set the gap to match the deepest point of the wall's bow, then run the scribe down the full height.
Cut along the scribed line with a fine-tooth saw, then test-fit. You'll usually need two or three passes, taking a little off each time, until the panel meets the wall with a consistent gap. DoorsDirect's made-to-measure side panels are designed to fit your opening, which can reduce the amount of scribing needed.
Step 4: Hanging Doors and Adjusting Alignment
Hanging the doors is where a good install becomes obvious and a bad one becomes obvious too. Sliding wardrobe doors hang from the top track on rollers, with the bottom track acting as a guide rather than a load-bearer. Get the sequence right and each door drops in cleanly.
Hanging sequence, one door at a time:
- Tilt the door and locate the top rollers into the top track first. The rollers sit in a channel, so you lift the door until the roller wheels clear the track lip, then lower them in.
- Swing the bottom of the door towards the bottom track and lower the bottom guide into its channel. The bottom guide is usually a small nylon block or wheel set into a groove, it should sit in the channel without forcing.
- Check the door hangs plumb before moving to the next one. A door that leans will bind against its neighbour no matter how well you adjust it later.
- Repeat for each door, working from one end of the opening to the other so you always have a reference edge.
Get help for anything over about 1.2m wide. A 25kg door is awkward rather than heavy, and dropping one can bend the roller carriage.
Understanding the adjustment screws:
Most sliding door systems give you two or three adjustment points per door, and knowing which does what saves a lot of trial and error:
- Height adjustment (usually on the top roller carriage): raises or lowers the door in the track. Use this to level the door against the carcass and to set an even gap at the top.
- Depth or tilt adjustment: moves the door in and out relative to the track, which controls how flush the door sits with the frame and how it meets its neighbour.
- Bottom guide adjustment: fine-tunes lateral play so the door runs true without rattling.
Turn adjustment screws a quarter-turn at a time and re-test. Small movements make a visible difference, and over-turning can strip the roller housing thread.
Diagnosing common alignment faults:
- Door drifts open or closed on its own: the track isn't level. A track that slopes even 2-3mm across a 1.8m opening is enough to make a door creep. Re-check with the spirit level and re-shim the track.
- Door binds or feels stiff along part of its travel: the tracks aren't parallel, or the bottom track has a high spot. Measure the gap between top and bottom tracks at both ends and the middle, it should be consistent.
- Door rattles: the bottom guide is too loose, or the roller height is set so the door sits off the bottom track. Adjust the guide and re-check.
- Door catches its neighbour: the depth adjustment is out, or the doors are hung in the wrong order. Check the overlap, sliding doors are designed to overlap by a set amount, usually 20-30mm, and hanging them in the wrong sequence reverses that overlap.
- Soft-close stops short or slams: the soft-close mechanism has a damper that can be adjusted or, on some systems, repositioned along the track. Check the manual for the specific mechanism.
Test the soft-close mechanism by sliding each door through its full travel. If a door stops short or drifts, the track isn't level or the roller height needs adjusting.
After adjustment, the final checks:
- All doors sit flush with each other and with the carcass
- Gaps top and bottom are even across the full width
- Each door slides through its full travel without binding or rattling
- Soft-close engages smoothly on every door
- Fixings are all tight and the track hasn't shifted during adjustment
Once these pass, the installation is done. Anything that fails here is almost always a track level or parallelism issue rather than a door fault, so go back to Step 3 before adjusting rollers again.
Common Mistakes, Maintenance and Waste Management
The most common mistakes are fitting tracks out of level, under-fixing the top track, and skipping the anchoring step. Each shows up later as doors that jump, bind, or sag.
On material-specific drilling: use a pilot drill sized to your screw when fixing into hardwood or MDF to avoid splitting, and switch to a masonry bit with the correct rawlplug for solid walls. The wrong bit is how panels crack.
Maintenance is simple. Clean tracks monthly and check roller adjustment every six months. Keep the soft-close mechanism free of dust, and re-tighten fixings annually.
Plan your waste before you start. Offcuts of MDF or timber can go to a local household waste recycling centre, and many suppliers take back packaging. Check your local council's guidance on household waste and recycling for what's accepted.
Conclusion
Fitting a made-to-measure wardrobe is a job where preparation decides the outcome. Get the measuring, levelling and track work right, and the doors will run smoothly for years.
DoorsDirect supplies made-to-measure sliding wardrobe doors and bespoke storage interiors cut to your dimensions, backed by a three-stage quality check process and a ten-year guarantee. Our Custom 3 Door Sliding Wardrobe Doors include the top and bottom track set, and our team offers expert guidance from measurement through to final fit, with nationwide delivery and trade support available.
Order yours today and fit a wardrobe built to your exact space.
Frequently Asked Questions
What tools do I need for wardrobe installation?
You will need a measuring tape, spirit level, power drill with masonry and wood drill bits, screwdriver, pencil, and a plumb line. For made to measure wardrobes, add a fine-tooth saw for scribing and spacer blocks for levelling. A stud finder helps locate wall studs for secure anchoring. Most DIYers complete the job with these basics, though a second person makes lifting doors and panels much easier.
How do I scribe wardrobe side panels to uneven walls?
Set the panel in place and use a pencil compass or scribing tool to trace the wall's contour onto the panel edge. Cut along the line with a fine-tooth saw, then test-fit. Repeat until the gap is minimal. This technique hides gaps up to 20mm and is essential for alcoves or older properties where walls are rarely straight. Take your time; a neat scribe looks far better than filler.
How do I ensure my sliding wardrobe door tracks are perfectly level?
Use a long spirit level (at least 1 metre) to check both the top and bottom tracks. Fix the bottom track first, packing it with spacer blocks if the floor slopes. Then align the top track directly above using a plumb line. Check level in both directions. Tracks out of level by more than 2mm cause doors to slide open or jump. Adjust packers before final tightening.
What are common mistakes in DIY wardrobe installation?
Fitting tracks before checking floor level, skipping wall anchoring into studs, and scribing too aggressively are frequent errors. Another is not leaving expansion gaps around the carcass. Always dry-fit components first, use the correct masonry fixings for your wall type, and follow the installation manual. If walls are very uneven, consider professional help or a made to measure solution that accounts for irregularities.
